eRacks/SOLO

The eRacks/SOLO is designedby dual-class E5-2600 v4/v3 processors, that support up to 44 core (2x 22 core) processing units. The system has up to 2TB of memory limit with high-frequency DDR4 ECC/REG memory stick in 16 DIMM slots.

eRacks/SOLO Enterprise server meets your workload and demands. eRacks/SOLO enterprise class servers give you the best hardware components and Open source tools that you need to innovate and accelerate your business. Get the best performance and stability within your price range with this system.

The 2U chassis with 3x 3.5-inch hot-swap bays provides flexibility for up to 36TB of raw storage array with 6x read and 3x write speed, which is gives the best performance for virtualization environments. Optional 1 x slim DVD-ROM drive bay is provided with this system.

Dual LAN with Intel® i350 Gigabit Ethernet Controller, Single LAN with Virtual Machine Device Queues reduce I/O overhead, Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output, Single LAN with Realtek RTL8211E PHY (dedicated IPMI) this system gives you the best network connectivity and management options.

While this system giving you all these excellent performances, it keeps the power usage at its’ minimum with eRacks/700w or eRacks/1000w power supply. That makes this system truly industry friendly and “Green Solution” for your enterprise.

No system could provide the best performance and protection against the disaster unless that is configured correctly. Keep that in mind eRacks System offers pre configurations according to your business demands and requirements including virtualization.

For your desire system please contact us or simply write in your request in the Notes field of your order. For orders with over 128GB memory, please call for special pricing. Other chassis / motherboard / processor configurations are possible. Email or call eRacks for a custom quote.




Features & Specifications

  • Chassis: 2U Rackmount with 6 Removal hard drive bays.
  • Power Supply: 700W/1000W Redundant Platinum Level (95%) Digital PS.
  • Motherboard: eRacks certified Dual-Intel Xeon Motherboard.
  • Processors: Dual socket R1 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4/v3 family (up to 44-Core)
  • Memory: Up to 2TB DDR4 (128GB 3DS LRDIMM) in 16x DIMM slots.
  • PCI-e Slots: 2x PCI-E 3.0 x16 Low-profile slot; 4x PCI-E 3.0 x8 Low-profile slot
  • LAN Ports: Intel® i350 Dual port GbE LAN 2x GbE LAN, 1x Dedicated LAN for IPMI Remote Management.
  • I/O Ports: 1x VGA, 1x COM port, 3x USB 2.0.
  • Hard Drive Bays: 3x 3.5" Hot-swap SATA Drive Bays and 1 x slim DVD-ROM drive bay.

  • System Cooling: 4x 8cm Heavy Duty fans with speed control.


Configure eRacks/SOLO

Choose the desired options and click "Add to Cart". You may also request a quote, please add additional requests and information in the "Notes" field. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).

Current Configuration
Base Price: $ 2495.00 As Configured: $ 2495.00
Configuration Summary:
Default Configuration
Option Choices More Info Add/Subtract
Chassiseracks/SOLO chassis 1U 3RHD
Power Supply700W Power Supply
Motherboarderacks/SOLO Dual-Intel Xeon Motherboard
Dual-class Intel Xeon ProcessorsIntel Xeon E5-2603 v4 (6 Cores @ 1.70GHz, PScore 5621)
Memory DDR4 ECC / REG4GB DDR4 Memory ECC / REG
RAID Configurationnone
Hard Drive Array250GB WD Re (Data Center) 7200rpm 3.5-inch SATA6 HDD
PCI 1LSI Logic MegaRAID SATA 4-Port
PCI 2none
Operating SystemUbuntu Linux 18.04 LTS Server Edition
Org Contribution$5 to the Ubuntu Studio Project
WarrantyStandard 1yr full /3yr limited warranty
Configurationnone
Notes Enter notes or custom instructions for this item here

To request a quote, please add additional requests and information in the "Notes" field, above. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).
