eRacks/PREMIUM

Intel® i5/i7/Xeon E3TM :  Energy-efficient performance

Enter any special requests in the Notes field of your order.

This server has 2 hotswap removable drive bays (3, 4 availavble with chassis upgrade), and uses a choice of Intel® TMi5/i7/Xeon processors, SATA6 hard drives, and DDR3 / DDR4 ECC memory.

There is also a 2U version of this system called the eRacks/PREMIUM2 . The 2U-height chassis allows more expansion, cooling, and more storage than the 1U-height chassis. This system is also available in a 3U chassis or other format.

Contact eRacks today for a custom quote, with your requirements - info@eracks.com.






Features & Specifications



The default configuration includes:

  • 1U-height Rackmount Chassis, 2, 3, or 4 Hotswap drives
  • Size: 1.75in(H) x 17.25in(W) x 23in(D) (Depths vary for upgrade chasses)
  • 300W power supply or higher
  • eRacks-certified Intel Single-CPU i3/i5/i7/Xeon motherboard, with 2GigE ports (4-ports available)
  • Intel i5/i7 or Xeon E3 Processor
  • High performance DDR3 / DDR4 ECC memory
  • Onboard dual Gigabit Ethernet (motherboard option for quad GbE)
  • Integrated Graphics Media Accelerator
  • DDR3 /DDR4 ECC Memory; up to 128GB, or up to 512GB or 1.5TB maximum RAM capacity with motherboard upgrade via custom quote
  • Two, Three, or Four hotswap removable SATA6 Hard Drive / SSD Bays
  • Slim DVD drive
  • PCIe slot available
  • Note: keyboard, mouse, or monitor not included


Configure eRacks/PREMIUM

Choose the desired options and click "Add to Cart". You may also request a quote, please add additional requests and information in the "Notes" field. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).

Current Configuration
Base Price: $ 1295.00 As Configured: $ 1295.00
Configuration Summary:
Default Configuration
Option Choices More Info Add/Subtract
Chassis1U eRacks/PREMIUM Chassis 2RHD 23" depth
Power Supply300w Power Supply for 1U rackmount chassis
MotherboardeRacks-certified Intel Single i5/i7/XeonE3 2GigE Motherboard
ProcessorIntel Core i5 2.8GHz CPU
Memory DDR38 GB DDR3 ECC/REG 1333MHz
Slim Optical Drive BaySlim DVD / CDRW
RAID Configurationnone
Removable Hard Drives2 x 500 GB SATA3 7200rpm Hard Drives
PCInone
PCI-enone
Rails and Bracketsnone
Keyboard and Mousenone
Operating SystemUbuntu Linux 18.04 LTS Server Edition
Org Contribution$5 to the Ubuntu Studio Project
WarrantyStandard 1yr full /3yr limited warranty
Notes Enter notes or custom instructions for this item here

To request a quote, please add additional requests and information in the "Notes" field, above. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).
