eRacks/TWINGUARD.PRO

The eRacks/TWINGUARD.PRO is a 1U system with 19.1 x 29.5 x 1.7-inch Dimensions, fully-redundant secure OpenBSD-based firewall server. This system comes with:33.5 lbs. or 15.2kg Gross Weight.

 Racks/TWINGUARD.PRO is simply two hot-swappable systems in a single 1U chassis and designed to provide double firewall security. While each internal system supports dual- Support Intel Xeon E5-2600 v4/ v3 Family Processors with up to 2TB high frequency DDR4 ECC/REG memory in 16 DIMM slots.

For te Data storage each system Node support 4x SATA 6Gb/s 2.5-inch SSD drives with RAID 0, 1, 5 or 10 arrays for data protection security. For connectivity and management 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port are included. As well as 2x USB 3.0 Ports, 1x VGA Port, 1x PCI-Express 3.0 x16 Slot (Low-profile) provided. For keeping the system cool, 3x Heavy-Duty Counter Rotating Fans w/ Air Shroud are included too.

For running the system smoothly, 1000W 80 PLUS Redundant Titanium Level (96%) AC-DC Power Supplies are added with each system node.

This system comes with failover capability, highly suitable for small offices and homes. Common Address Redundancy Protocol (CARP) is installed and configured on request. Web-based remote administration can also be installed free of charge, on request. Please state requests in the Notes field of your order.

Don't allow your firewall system to be a single point of failure!

In the event of a firewall failure, the secondary firewall automatically assumes the role of the primary and all network traffic flows uninterrupted. Optional installation available of pfw, the web frontend for the pf firewall in OpenBSD.

As always, these systems come with Standard 1yr full /3yr limited warranty.

Note: For orders with your desired configuration, use the Quote request button, eMail us, use the contact form, call us, or simply write in your request in the ‘Notes’ field when you place your order.


Features & Specifications

  • Form Factor: 1U Rackmount
  • Processor per Node: Dual LGA2011, Support Intel Xeon E5-2600 v4/ v3 Family Processors with up to 22 Cores each, up to 55MB Cache.
  • Memory per Node: 16x 288pin DDR4-2400/ 2133/ 1866/ 1600 DIMM Slots, Supports up to 2TB ECC/ 3DS Load Reduced Memory or up to 512GB ECC/REG Memory
  • Slots per Node: 1x PCI-Express 3.0 x16 Slot (Low-profile)
  • SATA per Node: 4x SATA3 Ports, Support RAID 0, 1, 5, 10
  • LAN per Node: Intel i350 Dual Port Gigabit Ethernet Controller; 1x Realtek RTL8201N PHY (dedicated IPMI)
  • Drive Bays per Node: 4x 2.5" Hot-swap SATA3 Drive Bays
  • Ports per Node: 2x USB 3.0 Ports, 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
  • Power Supply: 1000W 80 PLUS Redundant Titanium Level (96%) AC-DC Power Supplies w/ PFC
  • System Cooling: 3x Heavy-Duty Counter Rotating Fans w/ Air Shroud and Optimal Fan Speed Control
  • Front Panel: Buttons: Power On/Off, UID LEDs: Power Status, Network Activity, Universal Information (UID).


Configure eRacks/TWINGUARD.PRO

Choose the desired options and click "Add to Cart". You may also request a quote, please add additional requests and information in the "Notes" field. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).

Current Configuration
Base Price: $ 7985.00 As Configured: $ 7985.00
Configuration Summary:
Default Configuration
Option Choices More Info Add/Subtract
Base SystemRackmount/TwinG.PRO 1U-2X4RSSD Dual Nodes
Power SupplyeRacks/1000W Redundant Platinum Power Supply
MotherboardeRacks/TwinG.PRO 2IXE5M2T (up to 2TB DDR4 Memory in 16 DIMM slots)
Processor (node 1)Intel Xeon E5-2603 v4 (6 Cores @ 1.70GHz, PScore 5621)
Processor (node 2)Intel Xeon E5-2603 v4 (6 Cores @ 1.70GHz, PScore 5621)
System Memory4GB DDR4 Memory ECC / REG
Storage (Node 1)240GB Samsung PM Enterprise 2.5-inch SATA6 SDD
Storage (Node 2)240GB Samsung PM Enterprise 2.5-inch SATA6 SDD
LAN ports2x GbE Network Port, RJ45
PCI-e x16 (Node 1)none
PCI-e x16 (Node 2)none
Remote Management PortsIPMI port for Remote System Management
System CoolingHeavy duty counter rotating fan
Operating SystemOpenBSD
Org Contribution$5 to the OpenBSD Project
WarrantyStandard 1yr full /3yr limited warranty
Notes Enter notes or custom instructions for this item here

To request a quote, please add additional requests and information in the "Notes" field, above. Your quote request will be sent to your profile's eMail if you are logged in, otherwise enter the email address below (required only if not logged in).
